What are the mechanical properties of Oil Pipe Screws under high temperature and high pressure conditions?

Under high temperature and high pressure conditions, the mechanical properties of oil pipe screws are a key factor in ensuring the safety and reliability of pipeline connections. In this environment, screws need to withstand extreme working conditions, including challenges such as high stress, thermal expansion, corrosion and creep. The following is a detailed analysis of the mechanical properties of oil pipe screws under high temperature and high pressure conditions:

1. The impact of material selection on mechanical properties
High-strength alloy steel:
Under high temperature and high pressure conditions, high-strength alloy steel (such as 42CrMo, AISI 4140 or AISI 8740) is usually selected as the screw material. These materials have high tensile strength and yield strength and can resist plastic deformation under high pressure.
Stainless steel:
If there is a corrosive medium in the environment (such as hydrogen sulfide, carbon dioxide or salt water), stainless steel with better corrosion resistance (such as 316L, duplex stainless steel or super duplex stainless steel) can be selected. Although the strength of stainless steel may be lower than that of some alloy steels, its corrosion resistance and high temperature stability make it an ideal choice.
Super alloys:
Under extremely high temperatures (over 500°C) and high pressure conditions, nickel-based or cobalt-based super alloys (such as Inconel 718, Hastelloy C-276) can be used. These materials have excellent high-temperature strength, oxidation resistance, and creep resistance.
2. Effect of high temperature on mechanical properties
Decrease in tensile strength and yield strength:

With increasing temperature, the tensile strength and yield strength of metal materials will decrease significantly. For example, above 400°C, the strength of ordinary carbon steel may decrease by 30%-50%. Therefore, the appropriate material must be selected according to the actual working temperature.
Creep phenomenon:
At high temperatures, metal materials will undergo creep phenomenon, that is, plastic deformation gradually occurs under constant stress. In order to avoid connection failure caused by creep, materials with good creep resistance should be selected, and the working stress of the screws should be controlled within the allowable range.
Thermal expansion coefficient:
The difference in thermal expansion coefficients of different materials may cause the fit between the screw and the oil pipe to be loose or too tight. Therefore, thermal expansion matching needs to be considered during design to avoid leakage or damage caused by thermal stress.
3. Effect of high pressure on mechanical properties
Compression resistance:
Under high pressure conditions, screws need to withstand huge axial stress. If the tensile strength of the screw is insufficient, it may cause thread fracture or connection failure. Therefore, the minimum screw size and strength grade required must be calculated according to the working pressure.
Fatigue performance:
Under high pressure and vibration environment, screws may be subjected to periodic stress, which may cause fatigue fracture. In order to improve fatigue resistance, screws that have been quenched and tempered or surface strengthened can be selected.
Sealing performance:
Under high pressure conditions, the sealing performance of screws is crucial. Threaded connections may cause trace leakage due to high pressure, so it is necessary to combine sealing rings, raw tape or other sealing methods to enhance the sealing effect.
4. Common problems and solutions
Loose screws:
Under high temperature and high pressure conditions, screws may gradually loosen due to thermal expansion and vibration. To solve this problem, the following measures can be taken:
Use anti-loosening nuts or locking washers;
Apply thread locking glue (such as Loctite);
Increase the preload, but be careful not to exceed the yield strength of the screw.
Thread wear:
Under high pressure dynamic loads, threads may wear due to friction. The service life can be extended by:
Surface hardening of the threads (such as nitriding or chrome plating);
Using materials with higher wear resistance;
Regularly inspecting and replacing severely worn screws.
Stress corrosion cracking:
In environments with high temperature, high pressure and corrosive media, screws may suffer from stress corrosion cracking. Solutions include:
Selecting corrosion-resistant materials;
Reducing the working stress of the screws;
Applying anti-corrosion coating to the screws.

To ensure the reliability and safety of the screws, these factors should be considered comprehensively and the design should be optimized through rigorous testing and verification. The final selection should be based on the specific application scenario to ensure that the screws can meet the performance requirements throughout their service life.
